Description

ABB EI813F Industrial Automation Components and Industrial Control Accessories

Product Introduction

 https://www.dcsplc.cn

ABB EI813F is a multifunctional industrial automation module with multiple applications and functions. The following detailed product information can be summarized:

Product Overview
Model: EI813F 3BDH000022R1
Series: Part of the AC 800M I/O system.
Main purpose: Used in industrial automation systems as part of the control system to achieve data communication and information transmission.
technical parameter
Power supply voltage: 24V DC.
Input type: Digital input (8 channels).
Input voltage range: 0 V to+24 VDC.
Input current:<2 mA.
Sampling rate: 1 kHz.
Response time: 0.1 milliseconds to 10 seconds.
Working temperature range: -40 ℃ to+70 ℃.
Storage temperature range: -40 ℃ to+85 ℃.
Size: The sizes provided by different sources may vary slightly, such as 120mm x 75mm x 35mm, or 110mm x 60mm x 25mm.
Weight: Approximately 200 grams.
Installation method: 35mm DIN rail installation.
Functional Features
Communication interface: Supports Ethernet (IEEE802.3 standard, 10BaseT standard), RS-485, Modbus, TCP and other protocols.
Network interface: RJ45 Ethernet port, with a transmission rate of up to 10 MBit/s.
Compatibility: Used in conjunction with controllers such as PLC (Programmable Logic Controller) or DCS (Distributed Control System).
Other functions: Supports positive and negative logic, programming input filtering, upgrading fault flags, etc.
application area
Industrial automation: widely used in industrial automation systems for remote monitoring, control, and data transmission.
Motor protection: It integrates functions such as overload protection, phase loss protection, and short circuit protection to ensure the safe operation of motor equipment.
Voltage detection and protection: used to detect and protect voltage changes in AC power grids, with high precision and fast response characteristics.
