Description

GE SR469-P5-HI-A20-E terminal control and automation products have quality

Product Introduction

 https://www.dcsplc.cn

GE SR469-P5-HI-A20-E is a motor management relay produced by GE Multilin, belonging to the SR469 series. This device is designed for the management and protection of medium voltage motors and has multiple functions and features.

Main technical parameters:
Control power supply: Provide control power supply of 70-265 volts alternating current (AC) and 90-300 volts direct current (DC).
Phase CT secondary winding: A phase CT secondary winding with 5 amperes.
Front panel design: Includes an RS-232 program port interface with a baud rate of 9600 and programmable up to 19200 baud. The front panel is also equipped with a large LCD display screen that can display 40 characters of information, making it convenient for users to view diagnostic information such as trips or alarms.
Size: 70 x 123 x 56 millimeters.
Functional features:
Protection function: Provides multiple protection functions such as overload protection, undervoltage protection, phase failure protection, single-phase grounding protection, etc. In addition, it also has thermal protection function, providing comprehensive motor thermal protection using multiple RTD inputs.
Monitoring function: capable of monitoring various motor faults, such as overload, undervoltage, locked rotor conditions, and phase imbalance.
Reliability: Made with high-quality materials and processes to ensure high reliability.
Application areas:
This relay is suitable for motor protection and control in industrial automation systems, especially for medium voltage motor applications that require integrated management and protection.

GE SR469-P5-HI-A20-E terminal control and automation products have quality
