GE SR489-P5-LO-A20-E Panel Programmable Modular Industrial Control Product

Product Introduction

 https://www.dcsplc.cn

GE SR489-P5-LO-A20-E is a high-performance generator management relay belonging to the GE Multilin series. This device is mainly used for the protection and monitoring of induction and synchronous generators, and is suitable for various industrial applications.

Main functions and features
Voltage input:

Supports 20-60 VDC or 20-48 VAC, with a frequency range of 48-62 Hz.
Current input:

5A phase CT secondary.
Analog output:

Provide 4-20 mA analog output.
Communication interface:

The rear panel includes two RS485 communication ports, supporting Modbus RTU or DNP 3.0 protocols, with a maximum transmission rate of 19200 bps.
The front panel has an RS232 port interface.
Display and Panel:

Equipped with a 40 character display screen, allowing users to view value messages, diagnostics, and setpoints.
The front panel includes multiple status LEDs, numeric keypad, numerical up and down keys, control and programming keys (such as reset, input, menu, up and down keys).
Input port:

The rear panel contains twelve RTD inputs, six output relays, and four VT inputs.
The front panel has multiple status LEDs and input buttons.
Environmental adaptability:

The working temperature range is -40 ° C to+85 ° C (-40 ° F to+185 ° F), the relative humidity is between 5% and 95%, and there is no condensation.
CPU and other technical parameters:

Use a 32-bit RISC processor.
Designed to provide a wide range of protection, monitoring, and control functions, particularly for generator systems.
